CivilGrade


The CivilGrade was developed to withstand continuous use in the harsh environment of civil construction. With an overall width of 2.5m this machine is easily transportable and highly maneuverable whilst maintaining a significant payload capacity. When fitted with a dual receiver system, this machine will excel at any task.



Features

Apron with Mechanical Lock
Front Mounted Rippers
Independent Rear Axles
Unique CamTrack Design Ejector
Hose and Cylinder Protection
Integrated Tie-Down Points
50mm Tow Ball at Rear
Mast Hurdle
Trelleborg™ Flotation Tires
Hard Piping

Options

Roller
   - Rear mounted roller
Danfoss™ Valve
   - Proportional hydraulic control valve
Diverter Valve
   - Enables two functions to be run off one tractor remote
Hydraulic Pump and Tank
   - Independent hydraulic system powered by the tractors PTO

Machine Specifications

Model  CivilGrade Lite CivilGrade
Horsepower Range 95 - 160 HP 130 - 210 HP
Dimensions
Machine Width (mm) 2500 2500
Cutting Width (mm)  2270 2270
Length (mm) 5100  6000
Approximate Capacity (m3) 3.8 4.5
Weight (kg) TBC TBC
